| 80PLUS®
|
Platinum |
| Cybenetics Efficiency Level |
ETA-A () |
| Cybenetics Noise Level |
LAMBDA-A- () |
| Form Factor |
Intel ATX 12 V |
| Dimensions |
140 mm (L) x 150 mm (W) x 86 mm (H) |
| Fan Information |
Fan Size |
120 mm |
| Fan Control |
S3FC - Fanless until 30 % load |
| Fan Bearing |
Fluid Dynamic Bearing |
| Life Expectancy |
50,000 hours at 40 °C, 15 % - 65 % RH |
| Cable Information |
Modularity |
Fully Modular |
| Cable type |
Flat black cables |
| Electrical Features |
Operating Temperature |
0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan |
100,000 hours |
| AC Input |
Full Range |
| Protection |
OPP, OVP, UVP, OCP, OTP, SCP |
| Safety and Environmental |
Safety and EMC |
cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance |
Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Warranty |
10 Years |
