Product Details
＋
|
Model |
MPY-7501-AFAAG |
|
ATX Version |
ATX 12V V2.31 |
|
PFC |
Active PFC (>0.95 Typical) |
|
Input Voltage |
100-240V |
|
Input Current |
12-6A |
|
Input Frequency |
50/60Hz |
|
Dimensions (L x W x H) |
160 x 150 x 86 mm |
|
Fan Size |
120mm |
|
Fan Bearing |
LDB |
|
Power Good Signal |
100 - 500 ms |
|
Hold Up Time |
>14ms at 100% load |
|
Efficiency |
90% Typically |
|
ErP 2013 Lot 6 |
Yes |
|
MTBF |
>100,000 Hours |
|
Operating Temperature |
0-45∞C |
|
Protections |
OVP, OPP, UVP, SCP, OTP, OCP |
|
Regulatory |
CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
|
MB 24 Pin Connectors |
1 |
|
CPU 12V 4 4 Pin Connectors |
1 |
|
CPU 12V 8 Pin Connectors |
1 (for updated models) |
|
SATA Connectors |
8 |
|
Peripheral 4 Pin Connectors |
6 |
|
FDD Cable 4 Pin Connectors |
1 |
|
PCI-e 6 2 Pin Connectors |
4 |
|
Series |
MWE Gold Series |
|
Modular |
Full Modular |
|
80 Plus |
Gold |
